详细参数 / Detailed parameters
| Contact Rating | Max 0.4 VA max @48 VAC or DC |
| Mechanical Life | minimu 40,000 operations |
| Contact Resistance | 50 mΩ max. |
| Insulation Resistance | 500 MΩ at 250 VDC. |
| Dielectric Strength | 500V, 50Hz for the duration of 1 mimute |
| Operating Temperature | -20°C to 80°C |
| Degree of protecition | IP67 |
| Actuator | 2.80 hight |
| Terminal plating | Gold |
| Seal | EPOXY（std） |
| ROHS soldering | ROHS&Lead Free |
