详细参数 / Detailed parameters
| Rating | 2A/36V DC |
| Electrical life | 200,000 make-and-break cycles at full load |
| Mechanical Life | 1,000,000 cycles |
| Insulation Resistance | 1,000 mΩ min.at 500VDC |
| Dielectric Strength | 2,000 V rms @sea level. |
| Contact Resistance | 50 mΩ max. |
| Operating Temperature | -20°C ~+70°C |
| Travel | about 2.0±0.20mm |
| Operation pressure | 4.5N±1.5N |
| Ingress protection | IP67 |
| Torque | 11.5kgf·cm |
| Thickness | 8.0mm（Max.） |
